QZ- Series Miniature

名称:QZ- Series Miniature

  • 产品详情


Features

· AC Circuit Breaker

· Hydraulic-Magnetic Technology

· 100% Rating Capability Independent of

   Ambient Temperature

· Up to Three Poles

· CSA and VDE approved, CE certified

· UL Recognized (UL 1077 and UL 60947-4-1A)

· Ratings:  1 pole 40 A, 2 pole 30 A, 3 pole 30 A

· Optional Auxiliary / Trip Alarm Switch -

   Factory Fitted

· Wide Range of Time Delays and

  Operating Currents

· Precision Tripping

· Current Limiting Capabilities

· Ultra Compact – 13 mm Width Module

· Trip Indication with Mid-Trip Handle

· Reset Immediately After Overload


Applications

· UPS Equipment

· Mobile Power-Generation Equipment

· Power Conditioning Equipment

· Alternative Energy Equipment

· Lighting Control
